Equipment Supports
![](https://images.ctfassets.net/gz50xeghgvm0/3ZBA3N4ujDsP45jGB85Eok/c85cc0ae3bb82e76f085d62c6cc6fd53/CPES-1.png?fit=thumb&w=300&w=300)
![](https://images.ctfassets.net/gz50xeghgvm0/3ZBA3N4ujDsP45jGB85Eok/c85cc0ae3bb82e76f085d62c6cc6fd53/CPES-1.png?fit=thumb&w=50&w=50)
CPES-1 Conventional Roof Equipment Support
STANDARD FEATURES
18 ga. galvanized steel construction
Fully Welded One-Piece Construction.
Prime Painted after Fabrication.
Full Depth Internal C-Channel Reinforcing on 12" Centers.
6" Spreader Channels on 12" Centers.
Counterflashing Attached with Tek-Screws & Neoprene Washer.
Pressure Treated 2x4 Wood Nailer (3-1/2" Width).
Fully Mitered and Welded Raised 3" Cant.
Downloads
Specifications
- Specifications
- Conv Equip Support Spec 07720
![](https://images.ctfassets.net/gz50xeghgvm0/aiU82x09pTMSpQd5F1lg1/499fe7c99c823b28b6567d26ecdb8111/CPES-2.png?fit=thumb&w=300&w=300)
![](https://images.ctfassets.net/gz50xeghgvm0/aiU82x09pTMSpQd5F1lg1/499fe7c99c823b28b6567d26ecdb8111/CPES-2.png?fit=thumb&w=50&w=50)
CPES-2 Conventional Roof Equipment Support
STANDARD FEATURES
18 ga. galvanized steel construction
Fully Welded One-Piece Construction.
Prime Painted after Fabrication.
Full Depth Internal C-Channel Reinforcing on 12" Centers.
6" Spreader Channels on 12" Centers.
Counterflashing Attached with Tek-Screws & Neoprene Washer.
Pressure Treated 2x4 Wood Nailer (3-1/2" Width).
Fully Mitered and Welded 3" Cant.
Downloads
Specifications
- Specifications
- Conv Equip Support Spec 07720
![](https://images.ctfassets.net/gz50xeghgvm0/4kLwH16w40Z6ppjmJrlj1i/380aedc8281add6e3f8e87415f5a8c26/CPES-3.png?fit=thumb&w=300&w=300)
![](https://images.ctfassets.net/gz50xeghgvm0/4kLwH16w40Z6ppjmJrlj1i/380aedc8281add6e3f8e87415f5a8c26/CPES-3.png?fit=thumb&w=50&w=50)
CPES-3 Conventional Roof Equipment Support
STANDARD FEATURES
18 ga. galvanized steel construction
Fully Welded One-Piece Construction.
Prime Painted after Fabrication.
Full Depth Internal C-Channel Reinforcing on 12" Centers.
6" Spreader Channels on 12" Centers.
Counterflashing Attached with Tek-Screws & Neoprene Washer.
Pressure Treated 2x4 Wood Nailer (3-1/2" Width).
Downloads
Specifications
- Specifications
- Conv Equip Support Spec 07720
